Wooden Entrance Doors CLASSIC - Technical data
STANDARD VERSION
- door leaf is made of a special multi-layer panel reinforced with a solid wood frame and integrated stabilizers that prevent warping. Thermal conductivity of UP plate = 0.93 W/m2K.
- excellent thermal insulation UD (depending on the model, spruce) = 1.1 - 1.3 W/(m2K)
- double-layer insulating glass, Ug=1.1 W/(m2K)
- decorative frames and front panels are filled only on the outside
- double sealing and thermo-insulating threshold TB75
- 3-point locking and strong 3D adjustable hinges
- type of wood: spruce, oak, larch
- door leaf thickness 68 mm, frame thickness 68 mm
SPECIAL VERSION
- dimensions up to 125 x 270 cm
- possible production of transom and side elements
- certain models possible in low-energy version UD < 1.0 W/(m2K)
- certain models possible in passive version UD < 0.8 W/(m2K)
View from outside
View from inside
Side element ST02
